Xantrex PROsine 1800 Inverter Trusine 1800W 230AC/12DC - 806-1883

Xantrex PROsine 1800 True Sine Wave Inverter – 1800W, 230V AC / 12V DC – 806-1883

The Xantrex PROsine 1800 is a high-performance 1800W true sine wave inverter designed to deliver clean, reliable AC power from a 12V DC battery system. Ideal for marine, RV, off-grid, and international applications, the PROsine 1800 converts 12V DC into 230V AC, making it suitable for European appliances, power tools, and sensitive electronics.

Featuring true sine wave output, the PROsine 1800 provides utility-grade electricity, safe for laptops, TVs, medical equipment, and motor-driven devices. Its high surge capacity can handle startup loads for compressors, pumps, and other inductive loads. The inverter’s compact, rugged design allows flexible installation in tight spaces, while built-in protections ensure both the inverter and connected equipment remain safe.

Reliable, efficient, and easy to integrate, the Xantrex PROsine 1800 is an excellent solution for 12V battery systems requiring 230V AC power.

🔧 Technical Specifications

Electrical

• Inverter Type: True Sine Wave

• Continuous Power Output: 1,800 watts

• Surge Power: 3,600 watts

• DC Input Voltage: 12 VDC

• AC Output Voltage: 230 VAC ±5%

• Output Frequency: 50 Hz ±0.05%

• Maximum AC Output Current: 7.8 amps

• Peak Efficiency: Up to 90%

• No-Load Power Draw: Low idle consumption

Input & Output

• AC Receptacles: Hardwire terminal (optional outlet kits)

• DC Connections: Battery terminals

• Remote Control: Optional PROsine remote panel interface

Protection & Safety

• Overload and short-circuit protection

• Over-temperature shutdown

• Low battery and high battery voltage protection

• Reverse polarity protection

• Marine ignition protection compliant

Environmental

• Operating Temperature: 32°F to 104°F (0°C to 40°C)

• Cooling: Variable-speed, temperature-controlled fan

Physical

• Dimensions (L × W × H): Approx. 13.0″ × 7.0″ × 3.5″

• Weight: Approx. 9.5 lb (4.3 kg)

• Mounting: Horizontal or vertical

Certifications

• UL 458

• Marine ignition protection

• FCC Class B

Warranty

• 1-Year Manufacturer Warranty

⭐ Key Features

• 1,800W continuous true sine wave AC output

• Converts 12V DC to 230V AC, ideal for international appliances

• High surge capacity for motor-driven appliances

• Safe for sensitive electronics and power tools

• Compact, rugged design for marine, RV, and off-grid installations

• Optional remote panel for monitoring and control

• Advanced safety protections for overload, short-circuit, and temperature

Features:

• Two models available: 1000 watt (1500 watt surge) and 1800 watt (2900 watt surge)
• True sine wave output
• Removable LCD display can be mounted remotely for control and monitoring
• Unique DC terminals offer 180-degree connections for easy installation in tight places
• Efficient power save mode draws only 1.5 watts under no-load condition
• Two year warranty

Protection Features:

• Over temperature shutdown and automatic overload protection
• Over voltage and under voltage protection
• Short circuit and AC backfeed protection

Options:

• Available in 12 and 24 volt models
• Schuko AC receptacle
• Remote interface kit for remote mounting of display module
• Models available with Schuko, hardwire, or hardwire with transfer switch

Manufacturer : Xantrex
Manufacturer Part No : 806-1883
