Standard Horizon SCU-30 Wireless Base Station Unit

Key Benefits:

• Wireless integration: Converts handheld VHF radios into a base station for flexible onboard communication.

• Marine-ready durability: Water-resistant and built for harsh saltwater environments.

• Enhanced safety features: Includes emergency DSC capabilities for immediate distress alerts.

• Simple installation: Compact, lightweight, and easy to set up on any vessel.

• Full compatibility: Works with a wide range of Standard Horizon handheld radios.

• Clear audio performance: Delivers reliable communication even in noisy marine environments.

Core Functionality

• Multi-Unit Support: A single SCU-30 unit can support up to four wireless microphones simultaneously, making it ideal for larger vessels with multiple stations.

• Extended Range: Provides a reliable wireless connection with an operating range of up to 65 feet (20 meters) from the base station.

• Full Radio Control: Once connected, the wireless handsets can control almost all radio functions, including DSC distress calling, AIS displays, and intercom communication between stations.

Compatibility

The SCU-30 is specifically designed to work with high-end Standard Horizon fixed-mount radios and wireless microphones:

• Compatible Radios: GX2400 (Matrix), GX6000 (Quantum), and GX6500 series.

• Compatible Microphones: RAM4W (SSM-71H) and RAM4X (SSM-72H).

Technical Specifications

• Connection: Plugs directly into the RAM connector on the back of the radio via an included 5-foot (1.5m) cable.

• Power: Powered directly by the transceiver (13.8V DC), drawing a maximum of only 1.4W.

• Installation: Can be flush-mounted, bracket-mounted (included), or installed on a standard 1"-14 TPI extension pole.

• Durability: Built to withstand marine temperatures ranging from -4°F to +140°F.

What is in the Box

• SCU-30 Wireless Access Point with 5ft attached cable.

• Antenna Base/Socket (RA6054200) for standard mounting.

• Mounting Screws (M3X8 SUS).

• Owner's Manual.
