Maretron Solid-State Rate/Gyro Compass with 10m Cable & Connector - SSC300-01-KIT
Manufacturer Part #: SSC300-01-KIT
Couldn't load pickup availability
Maretron Solid-State Rate/Gyro Compass with 10m Cable & Connector
Model: SSC300-01-KIT
Sensor Type: Solid-State Rate/Gyro Compass
Cable Length: 10 meters (32.8 ft)
Connectivity: NMEA 2000
Application: Marine Heading, Rate of Turn & Stabilization Data
Ultra-Accurate Digital Heading & Rate-of-Turn Data
The Maretron SSC300 Solid-State Rate/Gyro Compass Kit delivers highly accurate digital heading, rate of turn, and stabilization data to your marine electronics network. Using advanced solid-state sensors (no moving parts), it provides reliable performance for chartplotters, autopilots, radar overlays, and motion-stabilized systems.
Plug-and-Play NMEA 2000 Integration
Designed for easy integration into NMEA 2000 networks, this kit includes a 10-meter cable and connector for flexible installation anywhere onboard. Simply connect it to your backbone and start delivering precise heading data to compatible displays and autopilot systems.
Solid-State Reliability (No Moving Parts)
Unlike traditional fluxgate compasses, the SSC300 uses solid-state rate/gyro technology—meaning no mechanical wear, faster response, and improved accuracy even in rough seas and high-speed maneuvers.
Ideal for Autopilots, Radar Overlay & Stabilization
This sensor is perfect for advanced marine systems that require precise heading and rate-of-turn information, including autopilot steering, radar/chart overlay alignment, and vessel motion compensation.
Key Features
-
Unmatched Accuracy: Better than 0.7° static heading accuracy and 1.5° dynamic heading accuracy in rough conditions.
-
Full Vessel Attitude: Provides high-speed updates for heading (20Hz), rate of turn (10Hz), and pitch/roll (10Hz).
-
Advanced Stabilization: Uses a micromachined 3-axis rate gyro and accelerometer to eliminate errors caused by boat motion.
-
Dual Protocol Output: Natively certified for NMEA 2000® and compatible with NMEA 0183 (requires optional cable for 0183).
-
IP67 Waterproof: Fully sealed, compact housing designed to withstand the harsh marine environment.
-
Auto-Calibration: Can be automatically calibrated for magnetic deviation using a Maretron display or N2KAnalyzer® software.
In The Box
| Component | Description |
| SSC300 Compass | Solid-State Rate/Gyro Compass sensor unit |
| 10m Connection Cable | NMEA 2000® Micro cable with connector (MARE-004) |
| Mounting Brackets | 2x brackets for deck or bulkhead installation |
| Mounting Hardware | Stainless steel bracket and mounting screws |
| User Manual | Comprehensive installation and calibration guide |
| Warranty Card | Official Maretron warranty registration documentation |
Technical Specifications
-
Model Number: SSC300-01-KIT
-
Operating Voltage: 9 – 16 Volts DC
-
Power Consumption: < 150mA (3 LEN)
-
Heading Resolution: 0.1°
-
Pitch/Roll Range: ±80°
-
Interface: NMEA 2000® (Level A) / NMEA 0183
-
Weight: 7 oz (198g) for the sensor unit
Note: For the most accurate results, the SSC300 should be mounted as close to the vessel's center of gravity as possible and away from large magnetic objects or high-current wiring.
Perfect For
-
Autopilot systems
-
Chartplotter radar overlay
-
Gyro-stabilized electronics
-
Offshore and performance boats
-
Advanced marine networks
