What does the Maretron NMEA 2000 Starter Kit include?

The Maretron NMEA 2000 Starter Kit includes a 5-meter Micro Powertap Cable, a 10-meter Micro Trunk/Backbone Cable, two Micro Tees, two 2-meter Micro Drop Cables, and two Micro Terminations, providing all the essentials to connect two devices on an NMEA 2000 network.

How easy is it to set up the NMEA 2000 Starter Kit on my boat?

The NMEA 2000 Starter Kit is designed for easy installation, with color-coded, durable brass connectors that simplify connecting multiple marine devices to your network, even for those with minimal technical experience.

Can I expand my NMEA 2000 network later with this starter kit?

Yes, this starter kit provides the basic components needed to connect two devices, and you can easily expand your NMEA 2000 network by adding additional cables or components compatible with the system.

What are the key features of the Maretron NMEA 2000 Starter Kit that ensure reliability?

The kit features gold-plated brass contacts and nickel-plated brass couplings, ensuring durability, excellent conductivity, and reliable connections in marine environments.

Popular right now
Lots of people have looked at this recently

Maretron NMEA 2000 Starter Kit 2 - CABLE-STARTER-2

Name: Maretron NMEA 2000 Starter Kit 2 - CABLE-STARTER-2
Brand: Maretron
SKU: 94110
Price: 211.99 USD
Availability: InStock

$211.99 ~~$245.00~~

SKU: 94110

Manufacturer Part #: CABLE-STARTER-2

Maretron NMEA 2000 Starter Kit 2 – CABLE-STARTER-2

Get your vessel’s NMEA 2000 network up and running quickly with the Maretron NMEA 2000 Starter Kit 2 (CABLE-STARTER-2) — a complete foundation kit that simplifies the setup of your marine digital backbone. Designed for boaters and technicians alike, this kit includes the essential cables and connectors needed to start a robust NMEA 2000 backbone capable of integrating multiple devices such as displays, sensors, instruments, and engine data modules.

Maretron’s NMEA 2000 Starter Kit 2 provides the building blocks of a reliable marine communication network. Using waterproof, marine-grade components, the kit allows you to daisy-chain devices and expand your system as needed, all while maintaining proper signal integrity and power distribution. Whether you’re installing gauges, GPS antennas, depth sensors, or tank senders, this starter kit gives you a clean and professional base for all NMEA 2000 devices on your vessel.

Ideal for small to mid-size craft, cruising boats, and DIY network builds, the Starter Kit 2 reduces clutter, installation time, and the guesswork of sourcing individual parts. With Maretron’s industry-trusted quality, you’re assured a future-ready backbone that supports expanding electronics needs.

Key Performance Features

High-End Durability: Unlike standard plastic connectors, Maretron uses nickel-plated brass couplings and gold-plated brass contacts. This provides superior corrosion resistance and a more reliable data connection in harsh saltwater environments.
Extended Reach: This kit is unique because it includes a 10-meter (32.8 ft) backbone cable, allowing you to run the network from the helm all the way to the engine room or transom on mid-sized vessels.
Plug-and-Play Expansion: The kit uses standard NMEA 2000 Micro connectors. To add a third or fourth device later, you simply need to buy an additional Tee and a drop cable.
Industrial Grade Shielding: Maretron cables are known for their heavy-duty shielding, which protects sensitive GPS and sonar data from electromagnetic interference (EMI) caused by engines or radios.

What's In The Box

The CABLE-STARTER-2 is a complete "network in a box." It includes:

1 x Micro Powertap: A specialized Tee with a 5-meter power lead to connect your network to the boat’s 12V DC battery.
1 x 10-Meter Micro Backbone Cable: The "trunk" line that runs the length of the boat.
2 x 2-Meter Micro Drop Cables: Used to connect your specific electronics (like a Chartplotter or VHF) to the backbone.
2 x Micro Tees: Used to join the drop cables to the main backbone.
2 x Male Micro Terminators: These must be installed at each physical end of the backbone to prevent signal reflection.

Technical Specifications

Brand: Maretron
Model: NMEA 2000 Starter Kit 2
Part Number: CABLE-STARTER-2
Network Standard: NMEA 2000 (IEC 61162-3)
Connectors: Sealed, waterproof NMEA 2000 standard connectors
Power: Designed to power NMEA 2000 backbone devices via included power cable
Application: Marine vessel digital data network foundation

Benefits

Speeds and simplifies initial NMEA 2000 installation
Reduces need to individually source cables and connectors
Supports integration of multiple marine electronics devices
Provides a clean, expandable backbone for future upgrades
Ideal for DIY installers, boat builders, and marine electricians

Applications

Creating a new NMEA 2000 network on recreational boats
Expanding existing backbone for navigation and monitoring gear
Marine instrumentation installations
Integrating engine and sensor data on vessels
Professional marine electronics wiring projects

Summary for the User

The Maretron Starter Kit 2 is the best choice if you are starting a network on a boat over 25 feet, where a standard 2-meter or 6-meter backbone won't reach from the dash to your power source or sensors. It is a "buy once, cry once" solution—it costs more than entry-level kits, but the brass fittings ensure you won't be chasing connection issues in three years.

Installation Tip: Always install your Powertap as close to the center of the backbone as possible. This ensures even voltage distribution to all devices on the network and prevents data errors caused by voltage drop.

Manufacturer : Maretron
Manufacturer Part No : CABLE-STARTER-2
