Lenco 101XD Extreme Duty Actuator - 12V - 2-1/4" Stroke - 5/16" Hardware - 15055-001

Lenco 101XD Extreme Duty Actuator – 12V | 2-1/4" Stroke | 5/16" Hardware | Model 15055-001

The Lenco 101XD Extreme Duty Actuator is a high-performance 12V marine actuator built for heavy-duty trim tab systems. With a 2-1/4" stroke and robust 5/16" hardware, this actuator provides precise, reliable movement for boats requiring durable, high-strength trim control.

Designed with marine-grade, corrosion-resistant materials, the 101XD actuator ensures long-lasting performance in both saltwater and freshwater environments. Its rugged construction and smooth, quiet operation make it ideal for larger boats or extreme-duty trim tab applications where reliability is critical.

Key Features:

• Voltage: 12V DC

• Stroke Length: 2-1/4"

• Hardware Size: 5/16"

• Model Number: 15055-001

• Extreme-duty design for demanding marine conditions

• Marine-grade, corrosion-resistant construction

• Smooth and quiet electric actuator operation

Benefits:

• Provides dependable lift for larger or heavy-duty trim tabs

• Improves boat stability, planing, and handling

• Durable and long-lasting in harsh marine environments

• Ideal for replacement or upgrade in extreme-duty trim tab systems

The Lenco 101XD Extreme Duty Actuator 15055-001 delivers the power, durability, and precision boaters need for optimal trim tab performance. It is a trusted solution for enhancing vessel control and handling under demanding conditions.

Specifications:

• Newly implemented Anti Extrusion Ring (AXR) seal stabilization system.
• Stronger top cap and mounting clevis design
• Improved pressure-tight torx screws
• Integrated wiper seal at actuator base
• Molded-in brass thrust bearing design
• Thicker and stronger motor housing wall
• Improved O-Ring design for more consistent seal
• Over-molded cable providing a stronger tighter seal
• Upper mounting bracket with gland seal

Features:

• Lenco's ballscrew design is more reliable and twice as powerful compared to typical hydraulics
• Lenco's tough, high-torque actuator motor easily pushes 500 pounds.
• Lenco Actuator connections use waterproof "Plug & Play" Deutsch connectors eliminating the possibility of water intrusion.
• 12 Volt
• 5/16" mounting hardware
• 6 foot cable

Keywords: Lenco 101XD actuator, 12V marine actuator, extreme duty trim tab actuator, Lenco 15055-001, heavy-duty trim tab actuator, 2-1/4" stroke actuator, marine trim tab actuator.

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Manufacturer : Lenco Marine
Manufacturer Part No : 15055-001
UPC : 874847003209
