Furuno SS60-SLTD/12 Stainless Steel Transducer - SS60-SLTD/12

SS60-SLTD/12 Stainless Steel Transducer

If a thru-hull flush-style transducer is called for, the Tilted Element SS60-SLTD/12 will accommodate a deadrise angle between 8° and 15°. This transducer compensates for deadrise by angling the element inside the housing.

The transducer is labeled with an arrow on top of the housing that should point towards the keel, whether it is installed to port or starboard. This ensures that the tilted element within the housing is given the correct orientation.

Features:

• 600 Watts

• 50/200 kHz

• 45/12 degree Beam Angles

• Stainless Steel Thru Hull with Temperature

• 30 Foot Cable with 10-Pin Connector

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.
Manufacturer : Furuno
Manufacturer Part No : SS60-SLTD/12
