BLUE SEA 8505 BREAKER PANEL AC 3 POS W MAIN - 8505

BLUE SEA 8505 BREAKER PANEL AC 3 POS W MAIN -

230V AC Main + Branch A-Series Toggle Circuit Breaker Panel

PN: 8505
White Switches

(1) 16A Double Pole Circuit Breaker Installed

(3) 8A Single Pole Circuit Breakers Installed

(1) 8247 AC Digital Multimeter w/ Alarm

Features:

• Red reverse polarity indicating LED

• All hot, neutral and safety ground buses installed, fully pre-wired

• All circuit label positions are backlit on standard panels - No kit required

• "ON" indicating LEDs installed in all circuit positions

• Maximum panel amperage - 50 Amperes

• MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance

• Two-part polyurethane slate gray finish

• Heavy 1/8" aluminum 5052 alloy

• Industry standard height and width

• Countersunk mounting holes throughout

• Detailed installation instructions and cutout template included

• Includes set of 30 common Large Format Labels

• Over 500 individual Labels available

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Manufacturer : Blue Sea Systems
Manufacturer Part No : 8505
UPC : 632085085056
