Raymarine i50 Tridata Display - E70060

Raymarine i50 Tridata Display – Depth, Speed & Temperature Instrument – E70060

The Raymarine i50 Tridata Display (E70060) delivers essential depth, speed, and water temperature data in a compact, easy-to-read marine instrument. Designed for both sailboats and powerboats, the i50 Tridata features a high-contrast three-line LCD with oversized digits and red backlighting for excellent visibility in all lighting conditions.

Compatible with SeaTalkng and NMEA 2000 networks, the i50 Tridata can operate as a standalone instrument with connected transducers or as a repeater within an existing Raymarine instrument system. Its standard footprint matches legacy ST60+ displays, making it an ideal upgrade solution. Reliable, energy-efficient, and simple to install, the i50 Tridata is a trusted choice for accurate onboard performance data.

🔹 Key Features & Benefits

• Displays depth, speed/log, trip distance, and water temperature

• High-contrast three-line LCD with oversized digits

• Red backlighting for excellent night-time visibility

• SeaTalkng native connectivity with NMEA 2000 compatibility

• Functions as standalone display or network repeater

• Low power consumption for extended cruising

• Same footprint as ST60+ instruments for easy upgrades

• Ideal for sailboats and powerboats

Technical Specifications — Raymarine i50 Tridata Display (E70060)

📟 Display & Functions

• Instrument Type: i50 Tridata digital display — depth, speed, log/trip, and water temperature all on one 3-line panel.

• Display Format: 3-line, high-contrast LCD with oversized digits.

• Backlighting: Red backlighting for excellent night-time visibility.

• Data Modes:

  • Depth (current, maximum/minimum)

  • Speed (through water, with additional data possible via network)

  • Log / trip data (distance traveled)

  • Water temperature

  • Additional modes on network: average/max speed, VMG, timers, alarms (varies by input and network).

⚡ Electrical

• Nominal Supply Voltage: 12 V DC (marine standard).

• Operating Voltage Range: 10 V to 16 V DC.

• Current Draw (Typical): 45–65 mA (display only).

• Current Draw (Max): 200 mA (with transducer connected).

• Power Consumption: < 1 W typical (display only), up to ~2.4 W max with transducer attached.

• NMEA 2000 Load Equivalency Number (LEN): 4.

🔌 Networking & Interfaces

• Network Compatibility: SeaTalkng (native), compatible with NMEA 2000 via adapter, and backwards compatible with SeaTalk.

• Transducer Interfaces: Built-in transducer connections for depth and speed/temperature sensors.

• Connections: Two SeaTalkng ports for network integration and transducer cables.

🏗️ Physical & Environmental

• Dimensions: Approx. 110 mm (W) × 115 mm (H) × 44 mm (D) (4.22″ × 4.52″ × 1.7″)

• Mounting: Surface mount standard (optional trunnion mount kit available separately).

• Waterproof Rating: IPx6 marine-rated for splash and spray protection.

• Operating Temperature: –20 °C to +55 °C (–13 °F to +131 °F).

• Storage Temperature: –30 °C to +70 °C (–22 °F to +158 °F).

• Relative Humidity: Up to 93 %.

📦 What’s Included (Typical)

• i50 Tridata instrument display

• Suncover and front bezel (matching i70s/p70s/eS Series & a/c/e Series)

• Gasket for flush mount

• 400 mm (15.7″) SeaTalkng spur cable

• SeaTalkng blanking plug

• Fixing screws and documentation.

📋 Notes

• Designed to fit in the same footprint as older ST60+ instruments, making upgrades easier.

• Can function as a master instrument (hosting its own transducers) or repeater on a networked installation.
