Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof - 206-051S

$23.99 $34.95
SKU: 29828

Manufacturer Part #: 206-051S


Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof - 206-051S

Panel Seal/Waterproof "A" Frame Magnetic Circuit Breakers

  • Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
  • Meets all American Boat and Yacht Council (ABYC) Standards for non-ignition protected circuit breakers
  • UL Recognized (UL 1077) for use in th USA, and CSA Certified for use in Canada
  • Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
  • Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
  • Handle Color - Metal with silicon rubber seal
  • Maximum Aperage - 50 Amps
  • Maximum Voltage/AIC - 32 VDC/2,500 amps with no back-up fuse (ABYC E-11.10.1.5.5)
  • Rated Switch Cycles - 10,000 actuations at rated current and voltage
  • Electrical Hardware - Hex nut 1/2-32 (supplied with circuit breaker); Lockwasher 1/2" internal tooth (supplied with circuit breaker)
  • Optional Boot - Black silicone rubber (P/N 048-015)
    Manufacturer : Paneltronics
    Manufacturer Part No : 206-051S
    UPC : 602290201404
