Lewmar Windlass Thermal Circuit Breaker Panel - 70Amp - 68000240

Windlass Thermal Circuit Breaker Panel - 70Amp

Panel mounted, a waterproof breaker that works with DC systems up to 48 volts. This trip-free breaker is ideal for a windlass circuit.

Features:

• Works with DC systems up to 48 volts
  • Clear, single lever operation
  • Combines switching and circuit protection into a single device
  • "Trip Free" design cannot be held "ON" during fault current condition
  • Ignition protected

Technical Specifications:

• Circuit Breaker Class - Type III
• Circuit Breaker Type - Thermally responsive bi-metal blade
• Maximum Voltage - 48V DC
• Amperage - 70Amp
• Mounting - Panel Mount
• Weight: -.5lb (0.23 kg)

*Sold as an Individual
