Lenco 12" x 30" Standard Trim Tab Kit without Switch Kit 12V – 15010-101
Manufacturer Part #: TT9X18
Couldn't load pickup availability
Lenco 12" x 30" Standard Trim Tab Kit without Switch Kit 12V – 15010-101
The Lenco 15010-101 is a 12" x 30" Standard Trim Tab Kit designed for larger boats that require maximum stability, lift, and precise trim control. With its oversized 12" x 30" trim tabs, this all-electric system enhances ride comfort, corrects side-to-side listing, reduces bow rise, and improves fuel efficiency by optimizing the boat’s running angle.
Built with marine-grade, corrosion-resistant materials, the Lenco 15010-101 is engineered to withstand harsh saltwater environments, ensuring long-lasting durability and consistent performance. Its 12V electric actuators provide fast, quiet, and reliable operation without the need for hydraulic pumps, hoses, or fluid.
This kit is supplied without a switch, making it perfect for replacement installations, upgrades, or custom helm setups using a compatible Lenco switch, LED indicator, or integrated control system.
Key Benefits
-
Oversized 12" x 30" trim tabs for maximum lift and stability
-
Improves ride comfort and handling in rough water
-
Reduces bow rise for faster planing and better visibility
-
Corrects side-to-side list caused by uneven loads
-
Enhances fuel efficiency through optimized hull attitude
-
All-electric operation—low maintenance, no hydraulics
Features
-
12V electric actuators for smooth, reliable, and quiet performance
-
All-electric trim tab system—no pumps, hoses, or fluid required
-
Marine-grade construction designed for saltwater durability
-
Compatible with Lenco standard tactile switches, LED indicator switches, and integrated systems
-
Built by Lenco Marine, a trusted leader in trim tab technology
Specifications
-
Model Number: 15010-101
-
Tab Dimensions: 12" x 30"
-
Voltage: 12V
-
Switch Kit: Not Included
-
System Type: Electric Trim Tab Kit
Ideal Applications
The Lenco 15010-101 is ideal for:
-
Large center console boats
-
Offshore and inshore fishing vessels
-
Walkaround and cruiser boats
-
Replacement or custom trim tab installations
The Electric Advantage
Lenco’s legendary electric actuators replace the slow response and maintenance headaches of hydraulic systems.
-
Instant Leveling: 12V electric actuators respond immediately to helm input, allowing for precise, real-time corrections of wind heel or shifting passenger weight.
-
Maintenance-Free: An oil-free design means no pumps to prime, no hoses to leak, and zero risk of hydraulic fluid entering the marine environment.
-
Submersible Durability: Built with high-impact, UV-resistant glass-filled nylon and double O-ring seals for a 100% waterproof, long-lasting solution.
Built for the Long Haul
-
Heavy-Duty Construction: Features 12-gauge 304 stainless steel blades with a 5/8" flared trailing edge for maximum strength and lift.
-
Custom Control Configuration: As a "No Switch" kit, this SKU is perfect for owners who want to choose their own control interface, such as the Lenco LED Indicator Switch or an integrated digital switching system.
-
Corrosion Resistance: All components are designed to withstand the harshest saltwater environments, from the laser-cut blades to the waterproof Deutsch connectors.
Technical Specifications
| Feature | Details |
| Model Number | 15010-101 |
| Blade Size | 12" Depth x 30" Width |
| Boat Length Range | 22' – 40' |
| Voltage | 12V |
| Material | 12-Gauge 304 Stainless Steel |
| Switch Included | None (Sold Separately) |
| Actuator Type | 101 Standard Actuators |
In the Box
-
(2) 12" x 30" Stainless Steel Trim Tab Blades
-
(2) 101 Standard Actuators with 6' leads and Deutsch plugs
-
(2) Upper Mounting Brackets with Gland Seals
-
(2) Lower Mounting Brackets (Pre-installed)
-
(1) Full Stainless Steel Mounting Hardware Pack
Upgrade your boat with the Lenco 15010-101 12" x 30" Standard Trim Tab Kit to enjoy superior stability, smoother rides, and dependable all-electric trim control.
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Manufacturer : Lenco Marine
Manufacturer Part No : TT9X18
Lenco 12" x 30" Standard Trim Tab Kit without Switch Kit 12V – 15010-101 is backordered and will ship as soon as it is back in stock.
