Xantrex Freedom X 2000 True Sine Wave Power Inverter - 12VDC - 120VAC - 2000W - 817-2000

Xantrex Freedom X 2000 True Sine Wave Power Inverter – 12V – 2000W (817-2000)

The Xantrex Freedom X 2000 True Sine Wave Power Inverter (817-2000) delivers reliable, high-quality AC power from a 12-volt DC battery system, making it ideal for marine, RV, truck, van, and off-grid power applications. Designed to run demanding loads and sensitive electronics alike, this inverter provides up to 2,000 watts of continuous power with a high surge capacity to start motors, compressors, and power tools with ease.

Featuring true sine wave output, the Freedom X 2000 ensures clean, utility-grade electricity for laptops, TVs, microwaves, medical equipment, and other sensitive electronics. Its compact, lightweight design allows for flexible installation in tight spaces, while advanced safety features protect against overload, over-temperature, over-voltage, and low battery conditions.

Engineered for durability and performance, the Xantrex Freedom X 2000 is a trusted power solution for mobile and off-grid lifestyles, delivering quiet, efficient, and dependable AC power wherever you need it.

🔧 Technical Specifications

Electrical

• Inverter Type: True Sine Wave

• Continuous Power Output: 2,000 watts

• Surge Power: 4,000 watts

• DC Input Voltage: 12 VDC

• AC Output Voltage: 120 VAC ±5%

• Output Frequency: 60 Hz ±0.05%

• Maximum AC Output Current: 16.7 amps

• Peak Efficiency: Up to 90%

• No-Load Power Draw: < 1.5 amps DC

Input & Output

• AC Receptacles: Dual GFCI-protected outlets

• Hardwire Capability: Yes

• DC Connection: Battery terminals

• Remote Control Compatible: Optional Freedom X remote panel

Protection & Safety

• Overload protection

• Short-circuit protection

• Over-temperature shutdown

• High and low battery voltage protection

• Ground fault protection (GFCI)

• Ignition protected (marine compliant)

Environmental

• Operating Temperature Range: 32°F to 104°F (0°C to 40°C)

• Storage Temperature Range: -4°F to 140°F (-20°C to 60°C)

• Cooling: Variable-speed, temperature-controlled fan

Physical

• Dimensions (L × W × H): Approx. 15.0″ × 7.5″ × 4.0″

• Weight: Approx. 11 lb (5.0 kg)

• Mounting: Horizontal or vertical

Certifications

• UL 458 (Power Converters/Inverters)

• Marine ignition protection compliant

• FCC Class B

Warranty

• 1-Year Manufacturer Warranty

⭐ Key Features

• 2,000W continuous true sine wave power for sensitive electronics

• High surge capacity for motor-driven appliances

• Compact and lightweight inverter design

• Dual GFCI-protected AC outlets

• Marine, RV, and off-grid approved

• Advanced safety and protection circuitry

• Optional remote panel for convenient system monitoring
